Product Overview
• Designed for applications with continuous operating temperatures up to 500°F (260°C)
• Media backed with woven fiberglasss crim will maintain effeciency even after repeated usage above 400°
• Ultra-fine high loft microglass media
• 24-gauge aluminized steel frame
• Media pack additionally supported by corrosion-resistant metal backing
• Aluminized steel face guard welded to downstream side prevents blowouts
• Same construction that exceeded all requirements of now-removed UL Class 1
Specifications
Effeciency | MERV8 |  |
FilterDepth | 2″,4″ | |
MediaType | Microglass | |
Frame Material | Corrosion-Resistant Steel | |
SpecialSizeAvailable | Yes | |
Antimicrobial Available | No | |
Max Operating Temperature | 500°F (260°C) | |
AirFiltrationCertification | UL900 |
Product Information
Part Number | Nominal Size Inches (W x H x D) | Actual Size Inches (W x H x D) | Std. Pkg. Qty. | Shipping Wt. Lbs. per Box | Cubic Ft. |
2″ | |||||
PFHT121202 | 12 x 12 x 2 | 11⁷⁄₁₆x11⁷⁄₁₆ x1¾ | 6 | 8.0 | 1.4 |
PFHT122402 | 12x24x2 | 11⁷⁄₁₆x23⁷⁄₁₆ x1¾ | 12 | 29.7 | 4.3 |
PFHT162002 | 16 x 20 x 2 | 15⁷⁄₁₆x19⁷⁄₁₆ x1¾ | 12 | 30.8 | 4.5 |
PFHT162502 | 16 x 25 x 2 | 15⁷⁄₁₆x24⁷⁄₁₆ x1¾ | 12 | 36.6 | 5.6 |
PFHT202002 | 20 x 20 x 2 | 19⁷⁄₁₆x19⁷⁄₁₆ x1¾ | 12 | 35.7 | 5.6 |
PFHT202402 | 20x24x2 | 19⁷⁄₁₆x23⁷⁄₁₆ x1¾ | 6 | 22.9 | 3.6 |
PFHT202502 | 20 x 25 x 2 | 19⁷⁄₁₆x24⁷⁄₁₆ x1¾ | 6 | 23.6 | 3.8 |
PFHT242402 | 24x24x2 | 23⁷⁄₁₆x23⁷⁄₁₆ x1¾ | 6 | 26.2 | 4.3 |
4″ | |||||
PFHT101004 | 10x10x4 | 9⁷⁄₁₆x9⁷⁄₁₆ x3¾ | 6 | 20.0 | 2.4 |
PFHT122404 | 12x24x4 | 11⁷⁄₁₆x23⁷⁄₁₆ x3¾ | 6 | 23.4 | 4.3 |
PFHT162004 | 16x20x4 | 15⁷⁄₁₆x19⁷⁄₁₆ x3¾ | 6 | 23.9 | 4.5 |
PFHT162504 | 16x25x4 | 15⁷⁄₁₆x24⁷⁄₁₆ x3¾ | 6 | 28.3 | 5.6 |
PFHT202004 | 20x20x4 | 19⁷⁄₁₆x19⁷⁄₁₆ x3¾ | 6 | 27.9 | 5.6 |
PFHT202404 | 20x24x4 | 19⁷⁄₁₆x23⁷⁄₁₆ x3¾ | 3 | 17.7 | 3.8 |
PFHT202504 | 20x25x4 | 19⁷⁄₁₆x24⁷⁄₁₆ x3¾ | 3 | 18.2 | 3.8 |
PFHT242404 | 24x24x4 | 23⁷⁄₁₆x23⁷⁄₁₆ x3¾ | 3 | 20.0 | 4.3 |
