Product Overview
• Dual-density media increases filter life and reduces operating costs
• Open header design prevents dirty air bypass and makes handling safe and easy
• Designed to perform in the most difficult operating conditions,suchas
variable air volume, turbulent air flows,and repeated fanshut down to 350°F
Specifications
Effeciency | MERV14,MERV13,MERV11 |  |
FilterDepth | 6″,12″ | |
MediaType | Dual-DensityMicrofiberglass | |
FrameMaterial | GalvanizedSteel | |
SeparatorStyle | CorrugatedAluminum | |
SpecialSizeAvailable | No | |
AntimicrobialAvailable | Yes | |
HeaderStyle(s) | Single,Double | |
MaxOperatingTemperature | 350°F(177°C) |
Product Information
Part Number | Nominal Size Inches (W x H x D) | Gross Media Area (Sq. Ft.) | Rated Airflow Capacity (CFM) | Std. Pkg. Qty. Per Carton | Shipping Wt. Lbs. per Box (± 7%) | Cubic Ft. |
MERV 14 Rated Filter Face Velocity: 500 FPM | ||||||
VFT14242412 | 24x24x12 | 125 | 2,000 | 1 | 19.0 | 4.7 |
VFT14202412 | 20x24x12 | 103 | 1,650 | 1 | 16.5 | 3.6 |
VFT14202012 | 20x20x12 | 84 | 1,400 | 1 | 14.0 | 3.0 |
VFT14122412 | 12x24x12 | 57 | 1,000 | 1 | 11.5 | 2.2 |
MERV 14 Rated Filter Face Velocity: 250 FPM | ||||||
VFT14242406 | 24x24x6 | 60 | 1,000 | 2 | 21.0 | 4.7 |
VFT14242406 | 20x24x6 | 49 | 825 | 2 | 18.5 | 4.0 |
VFT14242406 | 20x20x6 | 40 | 700 | 2 | 16.5 | 3.3 |
VFT14122406 | 12x24x6 | 27 | 500 | 2 | 13.5 | 2.4 |
MERV 13 Rated Filter Face Velocity: 500 FPM | ||||||
VFT13242412 | 24x24x12 | 105 | 2,000 | 1 | 18.0 | 4.3 |
VFT13202412 | 20x24x12 | 86 | 1,650 | 1 | 15.5 | 3.6 |
VFT13202012 | 20x20x12 | 70 | 1,400 | 1 | 13.0 | 3.0 |
VFT13122412 | 12x24x12 | 47 | 1,000 | 1 | 10.5 | 2.2 |
MERV 13 Rated Filter Face Velocity: 250 FPM | ||||||
VFT13242406 | 24x24x6 | 50 | 1,000 | 2 | 19.5 | 4.7 |
VFT13202406 | 20x24x6 | 41 | 825 | 2 | 17.0 | 4.0 |
VFT13202006 | 20x20x6 | 33 | 700 | 2 | 15.0 | 3.3 |
VFT13122406 | 12x24x6 | 22 | 500 | 2 | 12.0 | 2.4 |
MERV 11 Rated Filter Face Velocity: 500 FPM | ||||||
VFT11242412 | 24x24x12 | 105 | 2,000 | 1 | 18.0 | 4.3 |
VFT11202412 | 20x24x12 | 86 | 1,650 | 1 | 15.5 | 3.6 |
VFT11202012 | 20x20x12 | 70 | 1,400 | 1 | 13.0 | 3.0 |
VFT11122412 | 12x24x12 | 47 | 1,000 | 1 | 10.5 | 2.2 |
MERV 11 Rated Filter Face Velocity: 250 FPM | ||||||
VFT11242406 | 24x24x6 | 50 | 1,000 | 2 | 19.5 | 4.7 |
VFT11202406 | 20x24x6 | 41 | 825 | 2 | 17.0 | 4.0 |
VFT11202006 | 20x20x6 | 33 | 700 | 2 | 15.0 | 3.3 |
VFT11122406 | 12x24x6 | 22 | 500 | 2 | 12.0 | 2.4 |
